AUTOREDLINE GENERATED EXAMPLE

Automatically generated mechanical drawing redline

AutoRedline compares original and revised mechanical drawing PDFs and generates additions and strikeouts on the original drawing. Edit the generated marks in the review workspace, then export your reviewed redline PDF.

No upload or account required. Your demo edits stay in this browser session.

Processor housing · Rev A → Rev B Sample

Opening the drawing

Loading the AI markups and your saved decisions…

ORIGINAL → REVISED → GENERATED REDLINE

Source PDFs and actual generated output

This processor-housing example uses a public SM-0004 drawing with a synthetic test revision. The generated redline PDF is the saved AutoRedline engine output, before edits in this demo. It is not a customer drawing or a manufacturer revision history.

Download the redline and FAI evaluation kit: both workflows’ saved PDF and Excel examples, source drawings, provenance and review checklist. No account required.

Original processor housing drawing with two 18 mm standoffs and a rectangular support — Original drawing

Synthetic revised housing drawing with three 25 mm standoffs and an added bracket — Revised drawing

AutoRedline engine output with old standoff notes struck through, new requirements in red, removed support crossed out and added bracket geometry — Actual generated redline

Changes visible in the generated redline

Feature	Original	Revised	Generated marks
Standoff requirement	2X DIA 8 STANDOFF, HEIGHT 18	3X DIA 8 STANDOFF, HEIGHT 25	The old callout is struck through and the replacement is added in red. Height notes identify affected standoffs in the drawing views.
Standoff location S1	X 120 / Y 230	X 160 / Y 260	The old location note and X 120.0 dimension are struck through. The new location, dimension and standoff are marked in red.
Rectangular support	Item 3: rectangular support, 18 × 18 × 45	Support removed	The removed support is crossed out in the plan and isometric views, and its schedule row is struck through.
Bracket and schedule	No bracket or bracket-fixing hardware	Item 4: formed bracket; item 5: M3 fixing hardware	Bracket geometry and callouts are added in red, with replacement schedule rows for items 2, 4 and 5.

Edit the generated marks in the interactive review above, then download your reviewed PDF. The static files here remain unchanged. Automated output can miss or misinterpret changes; inspect every result before engineering approval or manufacturing use.

Source: Kayode Orimoloye / desireloft, SM-0004 processor housing. Source notices are retained in the PDFs.
